Toss PIREG-C2 - KASR Parameter Data; KONF Parameter Data

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 48 of 66
48
37
Parameter of calibrated calibration 6
1
SHORT_STRING
Name
“KAPK Par. Kal. 6”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
28
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Calibrated parameter of calibration 6:
Byte 0: s.a., see instance 32
… Byte 27
38
Parameter of calibrated calibration 7
1
SHORT_STRING
Name
“KAPK Par. Kal. 7”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
28
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Calibrated parameter of calibration 7:
Byte 0: s.a., see instance 32
… Byte 27
39
Parameter of calibrated calibration 8
1
SHORT_STRING
Name
“KAPK Par. Kal. 8”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
28
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Calibrated parameter of calibration 8:
Byte 0: s.a., see instance 32
… Byte 27
4.11.9. KASR parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
40
Calibration parameters modulation reserve
1
SHORT_STRING
Name
“KASR Aust.-R. R”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Modulation reserve (rrr) in % (0, 20…100)
Byte 1: calibrated modulation res. (kkk) in %
(20…100). Set to zero when writing.
41
Calibration parameters Calibrated modulation re-
serve
1
SHORT_STRING
Name
“KASR Aust.-R. K.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Calibrated modulation reserve (kkk) in % (20…100)
4.11.10. KONF parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
42
Configuration, Temperature nominal value control
1
SHORT_STRING
Name
„KONF Temp.-Soll.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Temperature nominal value control (0/1)
43
Configuration, Setting control
1
SHORT_STRING
Name
„KONF Einst.-St.“
2
USINT
Data type
C1h (BOOL)
3
USINT
Data length
1
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Setting control (1)
