16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 24 of 66
4.7.10. GADR command
Syntax Read: LGADR
RS232/USB: Response: AGADR aaa
Write: SGADR aaa
Response: OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Syntax: Read: Control set, BI = 07h
RS485: Response:
Write:
Response: short set, OK or error acknowledgement; response time max. 6 ms
Release: not in the On or calibration state
Description: Setting and querying the device address GA "aaa" (0...250) of the addressed RS232 and
RS485 communication. The factory setting is "000". If the device address is changed, the
acknowledgement is still made with the old device address.
Example Read: LGADR
RS232/USB: Response: AGADR 033
Write: SGADR 033
Response: QOK00
Example Read: 68 03 03 68 21 89 07 17 16 (GA=21h)
RS485: Response: 68 04 04 68 21 00 07 21 49 16
Write: 68 04 04 68 00 69 07 21 91 16 (GA=00 21h)
Response: 10 21 00 21 16
Reference: KOKO
4.7.11. GTYP command
Syntax Read: LGTYP
RS232/USB: Response: AGTYP ttt
Syntax: Read: Control set, BI = 6Bh
RS485: Response:
Description: Querying the device type "ttt" (line voltage,...) of the PIREG-C2 controller
Example Read: LGTYP
RS232/USB: Response: AGTYP 200
Example Read: 68 03 03 68 21 89 6B 15 16 (GA=21h)
RS485: Response: 68 05 05 68 21 00 6B C8 00 54 16
Reference: VERS
4.7.12. GWPA command
Syntax Read: LGWPA
RS232/USB: Response: AGWPA defg bbb ttt ±aaaa ±bbbb ±cccc
Syntax: Read: Control set, BI = 04h
RS485: Response: Long set with DB0…DB10
Description: Querying the following parameters to be used for the next calibration of the PIREG-C2:
- Settings "defg" (see below)
- Reference temperature "bbb" (0...50) in 1 °C
- Temperature range "ttt" (100...500) in 1 °C
Long set with DB0, BI = 07h
Long set with DB0 and DB1
