Toss PIREG-C2 - TOKG Parameter Data

16502 PIREG-C2 Gerätebeschreibung mit EtherNet_IP Bussystem191017 - EN.docx/ Page 52 of 66
52
61
8-point Tc correction of calibration 6
Temperature for controller and heating tape
1
SHORT_STRING
Name
“TKEK Kal. 6”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
56
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Controller and heating tape temperatures of the 8-
point Tc correction of calibration 2:
Byte 0 s.a., see instance 56
… Byte 55
62
8-point Tc correction of calibration 7
Temperature for controller and heating tape
1
SHORT_STRING
Name
“TKEK Kal. 7”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
56
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Controller and heating tape temperatures of the 8-
point Tc correction of calibration 2:
Byte 0 s.a., see instance 56
… Byte 55
63
8-point Tc correction of calibration 8
Temperature for controller and heating tape
1
SHORT_STRING
Name
“TKEK Kal. 8”
2
USINT
Data type
DAh (SHORT_STRING)
3
USINT
Data length
56
4
USINT
Access
01h (RPa - P)
5
USINT
Value
Controller and heating tape temperatures of the 8-
point Tc correction of calibration 2:
Byte 0 s.a., see instance 56
… Byte 55
4.11.15. TOKG parameter data
In-
stance
(ADI)
Attrib-
ute
Data type
Assign-
ment:
Description:
64
Temperature OK message, temperature lower limit
1
SHORT_STRING
Name
“TOKG Temp. Ug.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Lower limit (5…99 °C)
65
Temperature OK message, temperature upper limit
1
SHORT_STRING
Name
“TOKG Temp. Og.”
2
USINT
Data type
C6h (USINT)
3
USINT
Data length
1
4
USINT
Access
03h (RPa/WPa - C)
5
USINT
Value
Upper limit (5…99 °C)
66
Temperature OK message, stabilisation period
1
SHORT_STRING
Name
“TOKG Stab.-Zeit”
2
USINT
Data type
C7h (UINT)
3
USINT
Data length
2
4
USINT
Access
03h (RPa/WPa - C)
5
UINT
Value
Stabilisation period (0…999, in 0.1 s)
