TP-Link TL-SG5412F User Manual

4 Configur
e for
requirement 2
and 3
On ACL→ACL Config→ACL Create page, create ACL 100.
On ACL→ACL Config→Standard-IP ACL page, select ACL 100, create
Rule 1, configure operation as Deny, configure S-IP as 172.31.70.1 and
mask as 255.255.255.0, configure D-IP as 172.31.50.1 and mask as
255.255.255.0, configure the time-range as No Limit.
On ACL→ACL Config→Standard-IP ACL page, select ACL 100, create
Rule 2, configure operation as Deny, configure S-IP as 172.31.70.1 and
mask as 255.255.255.0, configure D-IP as 172.31.88.5 and mask as
255.255.255.255, configure the time-range as No Limit.
On ACL→ACL Config→Standard-IP ACL page, select ACL 100, create
Rule 3, configure operation as Permit, configure S-IP as 172.31.70.1
and mask as 255.255.255.0, configure D-IP as 172.31.88.5 and mask as
255.255.255.0, configure the time-range as work_time.
On ACL→Policy Config→Action Create page, add ACL 100 to Policy
limit1.
On ACL→Policy Binding→Port Binding page, select Policy limit1 to
bind to port 16.
5 Configure for
requirement 4
and 5
On ACL→ACL Config→ACL Create page, create ACL 101.
On ACL→ACL Config→Standard-IP ACL page, select ACL 101, create
Rule 1, configure operation as Deny, configure S-IP as 172.31.70.1 and
mask as 255.255.255.0, configure D-IP as 172.31.50.1 and mask as
255.255.255.0, configure the time-range as No Limit.
On ACL→ACL Config→Standard-IP ACL page, select ACL 101, create
Rule 2, configure operation as Deny, configure S-IP as 172.31.70.1 and
mask as 255.255.255.0, configure D-IP as 172.31.88.5 and mask as
255.255.255.255, configure the time-range as No Limit.
On ACL→Policy Config→Policy Create page, create a policy named
limit2.
On ACL→Policy Config→Action Create page, add ACL 101 to Policy
limit1.
On ACL→Policy Binding→Port Binding page, select Policy limit2 to
bind to port 18.
Return to CONTENTS
144

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
