Configuration Procedure:
Step Operation Description
1 Bind the IP address, MAC
address, VLAN ID and the
connected Port number of
the Host together.
Required. On the IP-MAC Binding page, bind the IP
address, MAC address, VLAN ID and the connected Port
number of the Host together via Manual Binding, ARP
Scanning or DHCP Snooping.
2 Enable the protection for the
bound entry.
Required. On the Network Security→IP-MAC Binding
→Binding Table page, specify a protect type for the
corresponding bound entry.
3 Specify the trusted port. Required. On the Network Security→ARP Inspection
→ARP Detect page, specify the trusted port. The specific
ports, such as up-linked port, routing port and LAG port,
should be set as Trusted Port.
4 Enable ARP Detect feature. Required. On the Network Security→ARP Inspection
→ARP Detect page, enable the ARP Detect feature.
11.2.2 ARP Defend
With the ARP Defend enabled, the switch can terminate receiving the ARP packets for 300
seconds when the transmission speed of the legal ARP packet on the port exceeds the defined
value so as to avoid ARP Attack flood.
Choose the menu Network Security→ARP Inspection→ARP Defend to load the following page.
Figure 11-14 ARP Defend
The following entries are displayed on this screen:
ARP Defend
159
