The following entries are displayed on this screen:
 Global Config
NDP: Select Enable/Disable NDP function globally.
Aging Time: Enter the period for the neighbor switch to keep the NDP packets
from this switch.
Hello Time: Enter the interval to send NDP packets.
 Port Config
Select: Select the desired port to configure its NDP status.
Port: Displays the port number of the switch.
NDP: Displays NDP status of the current port.
Enable: Click the Enable button to enable NDP for the port you select.
Disable: Click the Disable button to disable NDP for the port you select.
Note:
1. NDP function is effective only when NDP function is enabled globally and for the port.
2. The aging time should be set over the hello time value, otherwise the neighbor information
table of NDP ports will be unstable
14.2 NTDP
NTDP (Neighbor Topology Discovery Protocol）is used for the commander switch to collect NDP
information. NTDP transmits and forwards NTDP topology collection request based on NDP
neighbor information table, and collects the NDP information and neighboring connection
information of each device in a specific network range. The commander switch can collects the
specified topology in the network regularly and you can also enable topology collection manually
on the commander switch.
After the commander switch sends out NTDP request packets, lots of switches receive the request
packets and send out response packets at the same time, which may result in network congestion
and the commander switch overload. To avoid the above problem, two time parameters are
designed to control the spread speed of NTDP request packets.
 NTDP hop delay: Indicates the time between the switch receiving NTDP request packets and
the switch forwarding NTDP request packets for the first time.
 NTDP port delay: Indicates the time between the port forwarding NTDP request packets and its
adjacent port forwarding NTDP request packets over.
The NTDP function can be implemented on Device Table, NTDP Summary and NTDP Comfit
pages.
14.2.1 Device Table
On this page you can view the information of the devices collected by NTDP. Meanwhile, no matter
whether a cluster is established, on this page you can manually collect NTDP information at any
time to manage and control devices.
202

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
