TP-Link TL-SG5412F User Manual

Management Address
TLV
The Manag
ement Address TLV identifies an address associated
with the local LLDP agent that may be used to reach higher entities
to assist discovery by network management.
Port VLAN ID TLV The Port VLAN ID TLV allows a VLAN bridge port to advertise the
port's VLAN identifier (PVID) that will be associated with untagged
or priority tagged frames.
Port And Protocol VLAN
ID TLV
The Port And Protocol VLAN ID TLV allows a bridge port to
advertise a port and protocol VLAN ID.
VLAN Name TLV The VLAN Name TLV allows an IEEE 802.1Q-compatible IEEE
802 LAN station to advertise the assigned name of any VLAN with
which it is configured.
Link Aggregation TLV The Link Aggregation TLV indicates whether the link is capable of
being aggregated, whether the link is currently in an aggregation,
and if in an aggregation, the port identification of the aggregation.
MAC/PHY Configuration/
Status TLV
The MAC/PHY Configuration/Status TLV identifies: a)The duplex
and bit-rate capability of the sending IEEE 802.3 LAN node that is
connected to the physical medium; b)The current duplex and
bit-rate settings of the sending IEEE 802.3 LAN node; c)Whether
these settings are the result of auto-negotiation during link initiation
or of manual set override action.
Max Frame Size TLV The Maximum Frame Size TLV indicates the maximum frame size
capability of the implemented MAC and PHY.
Power Via MDI TLV The Power Via MDI TLV allows network management to advertise
and discover the MDI power support capabilities of the sending
IEEE 802.3 LAN station.
The LLDP module is mainly for LLDP function configuration of the switch, including three
submenus: Basic Config, Device Info and Device Statistics.
13.1 Basic Config
LLDP is configured on the Global Config and Port Config pages.
13.1.1 Global Config
On this page you can configure the LLDP parameters of the device globally.
Choose the menu LLDP→Basic Config→Global Config to load the following page.
191

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
