TP-Link TL-SG5412F User Manual

The following entries are displayed on this screen:
 Create Private VLAN
Primary VLAN: Enter the ID number of the Primary VLAN.
Secondary VLAN: Enter the ID number of the Secondary VLAN.
 Search Option
Search Option: Select a Search Option from the pull-down list and click the
Search button to find your desired entry in Private VLAN.
 Primary VLAN ID: Enter the Primary VLAN ID number of the
desired Private VLAN.
 Secondary VLAN ID: Enter the Secondary VLAN ID numbe
r
of the desired Private VLAN.
 Private VLAN Table
Select: Select the entry to delete or modify. It is multi-optional.
Primary VLAN: Displays the Primary VLAN ID number of the Private VLAN.
Secondary VLAN: Displays the Secondary VLAN ID number of the Private VLAN.
Port: Displays the Port number of the Private VLAN.
6.7.2 Port Config
The Private VLAN provides two Port Types for the ports, Promiscuous and Host. Usually, the
Promiscuous port is used to connect to uplink devices while the Host port is used to connect to the
he terminal hosts, such as PC and Server.
Choose the menu VLAN→Private VLAN→Port Config to load the following page.
Figure 6-15 Create and View Protocol Template
The following entries are displayed on this screen:
 Port Config
Port: Select the desired port for configuration.
Port Type: Select the Port Type from the pull-down list for the port.
74

TP-Link TL-SG5412F Specifications

General

MAC address table	8000 entries
Jumbo frames support	Yes
Maximum data transfer rate	1 Gbit/s
Supported data transfer rates	10, 100, 1000Mbps
Fan	0
Wi-Fi	No
Diagnostics	VCT
Management platform	SNMP, RMON, WEB/CLI/Telnet
Authentication method	802.1X, Radius
Packet transfer speed	17.99Mpps
Connectivity technology	Wired
Networking standards	IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
DHCP features	DHCP client
Security algorithms	SSH, SSL/TLS
Switch type	Managed
Switch layer	L2
Console port	RJ-45
Fiber optic connector	SFP
SFP/SFP+ slots quantity	12
Basic switching RJ-45 Ethernet ports quantity	4
Fiber ethernet cabling technology	100BASE-FX
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Stackable	-
Form factor	1U
Certification	CE, FCC
Product color	Black
Compatible operating systems	Windows 98SE, NT, 2000, XP, Vista, Windows 7\\r MAC OS\\r NetWare\\r UNIX\\r Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	260 mm
Width	440 mm
Height	44 mm
