CVHE-SVX005C-EN
Table 4. Representative weights, 60 Hz chillers (kg) (continued)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHF
350–570 588 050S 050S 9293 8157 10055 8919
350–570 588 050S 050L 9731 8501 10493 9263
350–570 588 050L 050L 10298 8875 11060 9637
350–570 588 050S 080S 10419 9057 11181 9819
350–570 588 050L 080L 12026 10232 12788 10994
350–570 588 080S 080S 14445 12246 14593 12571
350–570 588 080S 080L 14574 12391 15336 13153
350–570 588 080L 080L 15567 13088 16329 13850
350–910 957 080S 080S 14897 12875 16258 14236
350–910 957 080S 080L 15640 13457 17001 14818
350–910 957 080L 080L 16633 14154 17994 15515
350–910 957 080L 142L 20327 17084 21688 18444
350–910 957 142M 142L 21975 18389 23336 19749
350–910 957 142L 142L 22529 18803 23889 20164
1070–1300 1062 080L 142L 20734 17490 22094 18851
1070–1300 1062 142M 142L 22279 18693 23639 20053
1070–1300 1062 142L 142L 22832 19107 24193 20467
1070–1300 1062 142E 142L 23479 19554 24840 20915
1070–1300 1062 142M 210L 24976 20891 26336 22252
1070–1300 1062 142L 210L 25552 21305 26913 22666
1070–1300 1062 142E 210L 26199 21752 27559 23113
1070–1300 1062 210L 210L 28077 23555 29438 24915
1070–1300 1062 250E 250L 34542 28726 35903 30087
1470 1340 210L 210L 29279 24757 30640 26118
1470–1720 1340 142L 210L 26755 22508 28115 23868
1470–1720 1340 250E 250L 35744 29928 37105 31289
Notes:
1. TECU tubes, 0.71 mm tube wall thickness.
2. 2068.4 kPaG non-marine waterboxes.
3. Heaviest possible bundle and motor combination.
4. Operating weights assume the largest possible refrigerant charge.
5. Weights with starters assume the heaviest possible starter (AFD when it’s an allowed option).
6. Industrial Control Panel (INDP) option, add 23 kg.
7. Control Power Transformer (CPTR) option, add 59 kg.
8. Supplemental Motor Protection (SMP) option, add 227 kg.
Unit Clearances and Weights
