Table 5. Weights, 50 Hz chillers (kg)
Model
Comp Size
CPKW
Evap Size
Cond Size
Weights without Starters Weights with Starters
NTON EVSZ CDSZ
Operating Shipping Operating Shipping
CVHE
190–320
215
032S 032S
6706 6090 — —
231 — — 7464 6848
190–320
215
032S 032L
6981 6296 — —
231 — — 7739 7054
190–320
215
032L 032L
7364 6591 — —
231 — — 8122 7349
190–320
215
050S 050S
8934 7800 — —
231 — — 9715 8581
190–320
215
050S 050L
9395 8143 — —
231 — — 10176 8924
190–320
215
050L 050L
9901 8474 — —
231 — — 10721 9300
300–500
360
050S 050S
9665 8530 — —
379 — — 10255 9120
300–500
360
050S 050L
10126 8874 — —
379 — — 10716 9464
300–500
360
050L 050L
10670 9249 — —
379 — — 11260 9839
300–500
360
050S 080S
11305 9793 — —
379 — — 11895 10383
300–500
360
080S 080S
13943 12029 — —
379 — — 14534 12619
300–500
360
080S 080L
14664 12611 — —
379 — — 15254 13201
300–500
360
080L 080L
15580 13254 — —
379 — — 16171 13844
