EMTX-SVX01G-EN 49
Other Rover Software Tools
Air and Water Balancing Tool
Testing and balancing professionals can use the Air and Water Balancing tool to:
• Override individual or groups of variable-air-volume (VAV) boxes
• Calibrate the airflow in VAV boxes
• View the flow readings from VAV boxes
• Override fan control and water valves on equipment
• Create a balancing report
The Air and Water Balancing tool supports the following controllers:
• Tracer VV550 VAV controllers
• Controllers that use the LonMark Space Comfort Controller (SCC) profile.
IMPORTANT
The Air and Water Balancing tool works only with controllers that support the SCC
profile. In addition, the controllers must support the network variables for airflow. If
the Start Air Balancing button is not available on the Equipment tab, the controller is
not compatible with this tool.
Note: You cannot use the Air and Water Balancing tool remotely through Tracer Summit.
Rover 7.0 Air and Water Balancing Tool now allows you to change the network settings used while
performing this task. This means you can use this tool on non-Trane domains. To change the
network settings while using the Air and Water Balancing Tool:
1. Cli ck Settings (Figure 38).
2. The Network Settings dialog appears (refer to Figure 39, p. 50).
3. Set the Domain Length and Domain ID (hex) as described in “Defining the Discovery DSN,”
p. 45
4. Click OK.
Figure 38. Air and Water Balance Tool main screen for Rover 7.0
