4 Threat Protection System Hardware Specification and Installation Guide
Table 1. TPS 8200TX and 8400TX – hardware features
Feature TX Series devices
Ports Two fixed QSFP+ special purpose (SP) ports
One RJ-45 console port
One 1 GbE copper management port
Slots
• Model 8200TX – two I/O slots
• Model 8400TX – four I/O slots
Power supply Two hot-swappable 750W AC power supplies
System memory 128 GB DDR4-2133 DRAM (four 16 GB DDR4-2133
SDRAM per CPU)
External storage One 32 GB SSD
Replaceable fans 7 hot-swappable fans
High Availability (HA) Yes
In addition, the device includes:
• IPS inspection throughput: Up to 40 Gbps aggregate across all slots
• IPS + SSL inspection throughput: Up to 2 Gbps SSL inspection across all slots
• Mac-in-Mac support
• Device management through the LSM or centralized management through the SMS
