42 Threat Protection System Hardware Specification and Installation Guide
Pin number Signal name
8 Clear to Send (CTS)
RJ-45 Ethernet connectors
Provides pinout information for when your RJ-45 device is operating in 10Mbps/100Mbps mode.
Table 16. RJ-45 pinout information
Pin number Signal name
1 Transmit positive (Tx+)
2 Transmit negative (Tx-)
3 Receive positive (Rx+)
4 Ground (GND)
5 Ground (GND)
6 Receive negative (Rx-)
7 Ground (GND)
8 Ground (GND)
