18 Threat Protection System Hardware Specification and Installation Guide
When the device is managed by the SMS, a delay of up to 1 minute can occur before the SMS recognizes the
changed I/O module.
Note: When you insert a bypass I/O module, the bypass I/O module always starts up in bypass mode. A
bypass I/O module remains in bypass mode until you remove it from bypass mode through the CLI,
LSM, or SMS. Rebooting the TPS does not change the bypass mode of the bypass I/O module.
Supported transceivers and cables for TippingPoint I/O modules
Table 7. Supported transceivers for I/O modules
I/O module & part number Transceiver
part number
Transceiver name
6-Segment GbE SFP (TPNN0068) TPNN0054
TPNN0055
TPNN0056
TippingPoint X126 1G SFP RJ45
Transceiver
TippingPoint X126 1G SR Fiber SFP
Transceiver
TippingPoint X126 1G LR Fiber SFP
Transceiver
4-Segment 10 GbE SFP+
(TPNN0060)
TPNN0057
TPNN0058
TPNN0054
TippingPoint S136 10G SFP+ LC SR
Transceiver
TippingPoint S136 10G SFP+ LC LR
Transceiver
TippingPoint X126 1G SFP RJ45
Transceiver
1-Segment 40 GbE QSFP+
(TPNN0069)
TPNN0067 TippingPoint S146 40G QSFP+ SR4
850nm Transceiver
Technical specifications
The TPS TX Series devices have the following specifications.
