System status indicator
The System Status indicator is located on the right side of the front panel and indicates the current operating
status of the appliance.
• Flashing Green — Appliance is booting and is not yet ready to inspect traffic.
• Flashing Green/Yellow — Appliance is booting and BIOS or software is updating.
• Solid Green — Appliance is running in a healthy state.
• Solid Yellow — Appliance is running but has a health rating below the acceptable threshold.
Alert indicator
The Alert indicator is located on the right side of the front panel and indicates the current status of the
software processes and the hardware.
• Solid Green — Both the hardware and the software processes are running normally.
• Solid Yellow — System is booting. If the solid yellow indicator remains after startup, a software
problem has been detected. Hardware status is undefined.
• Flashing Yellow — Hardware problem detected. Software running normally.
• Off — Appliance power is off.
Fans and power supplies
The 2200T device includes two hot-swappable power supplies. For more information, see Power supplies on
page 43.
Note: The 2200T device includes three cooling fans. The fans for the 2200T device are redundant but not
hot-swappable. If a failure to a fan module occurs, you must replace the entire device.
External storage card
The TPS 2200T device includes a CFast card slot. The external storage card stores traffic logs, snapshots,
and other system data. The card can be removed and inserted while the device is running; however, to do so,
you must issue the appropriate unmounting, mounting, and preparation commands in the device CLI.
For more information, see External user disk on page 50 or the TPS CLI Reference for command syntax.
Ports
The 2200T device is equipped with eight RJ-45 ports that include integrated bypass support. In addition, the
device provides a console and management port as shown in the following figure:
