Threat Protection System Hardware Specification and Installation Guide 25
In addition, the 2200T is equipped with eight 1G SFP ports and 4 10G SFP+ ports. ZPHA bypass support
for SFP/SFP+ is provided through an external ZPHA device.
Model requirements
The following topics describe specific requirements for the 2200T device.
• Power requirements on page 25
• Cabling requirements on page 25
Power requirements
The TPS 2200T device requires Alternating Current (AC) that meets the following requirements:
• AC: Voltage 100V to 240V; 12 to 6A; 47 to 63 Hz
The TPS 2200T device ships with two AC power supplies.
Cabling requirements
The TPS 2200T device ships with the following cables:
• Two AC power cables, one for each hot-swappable power supply
• Null modem cable (USB to RJ-45) for the serial console management port shown in Figure 9 on page
24
Pluggable transceivers
The 2200T device supports the following SFP and SFP+ pluggable transceivers:
• 1G SFP RJ45 T (Copper SFP)
• 1G SFP LC LX 10km 1310nm XCVR
• 1G SFP LC SX 550m 850nm XCVR
• 10G SFP+ LC SR
• 10G SFP+ LC LR
Note: Only optical transceiver modules (including SFP and SFP+) available from TippingPoint have been
validated to achieve optimal performance with TippingPoint products. Other vendor devices are not
supported. Using other vendor devices could be detrimental to proper operation of the TippingPoint
system.
The following table details the information for SFP and SFP+ transceivers.
