Threat Protection System Hardware Specification and Installation Guide 41
Connector and cable pinout specifications
This information provides connector and pinout information for TPS devices and contains the following
topics:
• RJ-45 (COM) console on page 41
• RJ-45 Ethernet connectors on page 42
RJ-45 (COM) console
Describes the RJ-45 (COM) console specifications.
The following figure displays the RJ-45 connector and the following table shows the RJ-45 console
connector pinouts.
Figure 14. RJ-45 connector
Table 15. RJ-45 console connector pinouts
Pin number Signal name
1 Request to Send (RTS)
2 Data Terminal Ready (DTR)
3 Transmit Data (TxD)
4 Ground (GND)
5 Ground (GND)
6 Receive Data (RxD)
7 Data Set Ready (DSR)
