Threat Protection System Hardware Specification and Installation Guide 17
Feature LED Color Description
Activity Blinking Amber Data traffic passing.
Optical transceiver port Link
Activity
Green
Amber
Link is active.
Data traffic passing.
Module health Status Green
Blinking Amber
Solid Amber
The module is configured, in
service, and in good health.
The module has been inserted
and powered up, but is not yet
recognized by the software.
The module is experiencing a fault.
Bypass Status Off
Green
Module in bypass.
Module in normal mode (not in
bypass).
I/O module replacement
On a TPS TX Series device, hot swapping allows you to add, remove, or replace an I/O module without
shutting down the device. When the device is turned on, you can hot swap an I/O module without
interruption to the TPS device.
Note: Hot-swapping I/O modules during system initialization is not supported.
When you hot swap an I/O module, keep the following points in mind:
• The module port configuration is always reset.
• The module segment configuration, including link-down synchronization, Intrinsic HA, and inspection
bypass, is always preserved.
When the device is turned off, cold swapping allows you to add, remove, or replace an I/O module as you
would when you hot swap. However, when you cold swap an I/O module, if the replacement module type is
the same, the module port configuration is preserved.
