Threat Protection System Hardware Specification and Installation Guide 43
Power supplies
This topic provides information for using the power supply modules. The following subjects are discussed.
• AC power supply – TPS 2200T and TX Series on page 43
• DC power supply – TPS TX Series on page 44
Warning!
This product might have more than one power supply source. All power sources must be
removed to de-energize the unit.
Note: The TPS 2200T device has hot-swappable power supplies; there are no other serviceable parts inside.
There are no hot-swappable or serviceable parts inside the TPS 440T device.
AC power supply – TPS 2200T and TX Series
The TPS 2200T and TX Series devices include two power supply modules. The modules are hot-swappable,
redundant, and current-sharing, and the appliance can run with one active module.
Figure 15. 2200T AC power supply
1. Removal Latch
2. Handle
3. Status LED
4. AC male power input
