44 Threat Protection System Hardware Specification and Installation Guide
The Status LED is green when the module is powered and running normally.
Connect the AC power supply
Describes how to connect the power supply to your device.
When the AC power supply has been securely placed in the device, use the following procedure to connect
power to the AC power supply:
1. Locate the male power input on the back of the chassis.
2. Plug one end of a standard female power plug into the power input.
3. Plug the other end into an AC outlet, power strip, or UPS. For information about the power
requirements for your product, see the following sections:
• TX Series devices – Technical specifications on page 18
• 2200T device – Technical specifications on page 26.
• 440T device – Technical specifications on page 32
The TPS device returns to its previous power-on state in the event of a power interruption. If power
was on when the interruption occurred, the device automatically powers back on when the power is
reconnected; if power was off, the device stays off when the power is reconnected. If necessary, power
on the device with the button on the front of the chassis.
DC power supply – TPS TX Series
The TPS TX Series devices are NEBS compliant and can accept a combination of AC and DC power supply
units. Consult your TippingPoint account contact for more information on obtaining DC power supplies.
Warning!
Do not attempt to install a DC power supply into a 440T device. The 440T device does not
contain the grounding capability for safe installation of a DC power supply. Bodily harm and
damage to the system could result.
Connect the DC power supply
Warning!
When installing the product, always make the ground connection before applying power to
the unit. This equipment needs to be grounded to an external ground connection. Use a green
and yellow 12 AWG ground wire to connect the host to earth ground during normal use.
Disconnect the ground connection only when the unit is completely powered down.
Caution:
Do not attach a ground wire to the ground screw on the DC power supply module. Attach
the ground wire to the 2200T chassis DC grounding screw holes (0.63-inch hole spacing) with
#10 screws. The DC grounding screw holes are located in the rear of the chassis.
The power supply LED is green when the module is powered and running normally.
