26 Threat Protection System Hardware Specification and Installation Guide
Table 10. Fiber input details
Fiber Input Signal
Left side Transmit
Right side Receive
Technical specifications
The TPS 2200T device has the following specifications.
Table 11. TPS 2200T – technical specifications
Specification Description
Dimensions
(unpackaged)
2U form factor – 3.46 in (H) x 16.77 in (W) x 18.80 in (D) (8.80 cm x 42.60 cm x
47.80 cm)
Weight 26.26 lbs (11.91 kg)
Power Requirements AC: Voltage 100 to 240; Current 12 to 6A; Frequency 47to 63 Hz
The appliance’s maximum power consumption is 493W.
Service Provider
operating
requirements
Temperature: 32 to 104° F (0 to 40° C) — Operating
Temperature: -4 to 158° F (-20 to 70° C) — Storage
Altitude: No degradation up to 10,000 feet (3048m)
Humidity: 5% to 95% (non-condensing)
External interfaces
• One 1 GbE copper management port
• One RJ-45 console port
