Threat Protection System Hardware Specification and Installation Guide 19
Table 8. TPS 8200TX and 8400TX – technical specifications
Specification Description
Dimensions
(unpackaged)
• 8200TX (1U form factor) – 1.73 in x 18.54 in x 24.84 in (44 mm x 428 mm x
631mm)
• 8400TX (2U form factor) – 3.46in x 18.54 in x 24.84 in (88mm x 428 mm x
631 mm
Weight
• 8200TX – 32 lbs (14.5 kg)
• 8400TX – 50 lbs (22.7kg)
Power Requirements
• AC: Voltage 100 to 240; Current 12 to 6A; Frequency 47to 63 Hz
• DC: Voltage -40 to -60, Current 24 to 16A, SELV
The device’s maximum power consumption is 750W.
Service Provider
operating
requirements
Temperature: 32 to 104° F (0 to 40° C) — Operating
Temperature: -4 to 158° F (-20 to 70° C) — Storage
Altitude: No degradation up to 10,000 feet (3048m)
Humidity: 5% to 95% (non-condensing)
External interfaces
• One 1 GbE copper management port
• One RJ-45 console port
• Two fixed QSFP+ special purpose (SP) ports
• Network slots:
◦ 8200TX – 2 slots
◦ 8400TX – 4 slots
• 1 SSD slot
