© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-718BRM
29
Universal Repeater
Setup > Wireless Settings
Universal Repeater mode allows the modem router to function as a wireless extender or
repeat the signal of another wireless access point or router in order to extend or
broaden the signal coverage. The diagram displays the modem router in universal
repeater mode repeating/extending the signal of an existing wireless router in order for
laptop computers to establish better wireless connectivity in an area with weak signal
coverage. When enabling this mode, the modem router’s DHCP server will be disabled
automatically.
1. Log into your router management page (see “Access your router management page
on page 35).
2. Click on Setup, and click on Wireless Settings.
3. Click the Wireless Operation Mode drop-down list and select Universal Repeater.
4. Click the Scan button at the bottom of the page.
5. A list of available wireless networks will appear at the bottom of the page. Click Select
next to the wireless network you would like to repeat. The selected entry will populate
the fields at the top of the page. Enter the wireless network encryption key if necessary.
6. To save changes, click Apply.
Note: If you would like to discard the changes, click Undo before you click Apply.
7. If prompted to reboot in order to apply changes, click Reboot at the bottom of the
page and click OK or Continue to reboot the device.

Table of Contents

Other manuals for TRENDnet TEW-718BRM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TRENDnet TEW-718BRM and is the answer not in the manual?

TRENDnet TEW-718BRM Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Modulation16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, OFDM, QPSK
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity13 channels
Top Wi-Fi standardWi-Fi 4 (802.11n)
WLAN data transfer rate (max)150 Mbit/s
Rack mountingNo
Frequency band2.4 GHz
Frequency range2.4 - 2.4835 GHz
WLAN data transfer rates supported11, 54, 150 Mbit/s
Ethernet LAN (RJ-45) ports4
DSL specificationG.992.1, G.992.2, G.992.3, G.992.5
DHCP client-
Routing protocolsIGRP, IP, RIP-1, RIP-2
Security algorithms128-bit WEP, 64-bit WEP, WPA, WPA-PSK, WPA2-PSK
Antennas quantity1
CertificationCE, FCC
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)5 W
Storage temperature (T-T)-10 - 70 °C
Operating temperature (T-T)0 - 40 °C
Product colorBlack
LED indicatorsDSL, LAN, WLAN
Weight and Dimensions IconWeight and Dimensions
Depth189 mm
Width118 mm
Height33 mm
Weight221 g
