TEW-740APBO #1
1. Remove the tab on the far left by gently bending it back and forth until the tab is
removed. This will create the opening the RJ-45 network cable to be routed through.
2. Using a RJ-45 network cable, connect one end of the cable to the LAN (PoE) port and
push the cable into the guide on the far left, then through the opening that was created
in the previous step.
3. Connect the other end of the RJ-45 network cable to the P+DATA OUT port on the
included PoE injector.
4. Using another RJ-45 network cable, connect one end of the 10/100 DATA IN port on
the included PoE injector.
5. Connect the other end of the RJ-45 network cable to your computer’s Ethernet port.
6. Connect the included power adapter to the PoE injector POWER IN on the included
PoE injector.
7. Plug the connected power adapter into a power outlet.
8. Confirm the device is powered on through the PWR LED indicator.
