Setup and Confirm Connectivity
1. Remove the cover of the access points by pulling and holding the tab in the vertical
direction upward (as shown in the picture below) and sliding the cover in the two
locations noted away from the access point.
2. Remove the tab on the far left by gently bending it back and forth until the tab is
removed. This will create the opening the RJ-45 network cable to be routed through.
3. Using a RJ-45 network cable, connect one end of the cable to the LAN (PoE) port and
push the cable into the guide on the far left, then through the opening that was created
in the previous step.
