TRENDnet TEW-750DAP User Manual

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide
TEW-750DAP
16
PBC (Software/Virtual Push Button)
Wireless > Wi-Fi Protected Setup
In addition to the hardware push button located physically on your access point, the
access point management page also has push button which is a software or virtual push
button you can click to activate WPS on your access point.
1. Log into your access point management page (see “
Access your access point
management page” on page 11).
2. Click on Wireless, and click on Wi-Fi Protected Setup.
3. To add a wireless device to your network, click the Connect button in the access point
management page.
4. Make sure Auto is selected and click Next.
5. Select PBC and click Connect. Then push the WPS button on the wireless device
(consult wireless device’s User’s Guide for length of time) you are connecting.
6. Wait for your access point to finsh the WPS process.
7. If successful, you will receive the message below. Click on Wireless Status to view the
information about the current wireless client devices connected to your access point.

TRENDnet TEW-750DAP Specifications

Operating Environment

operating temperature	0 - 40 °C
operating humidity	Max. 95% non-condensing

Power

input voltage	100 - 240 V AC
output voltage	12 V DC
power consumption	10.1 Watts

Antenna and Wireless

antenna gain 2.4 GHz	2 x 1.5 dBi
antenna gain 5 GHz	2 x 4 dBi
wireless output power 802.11a	15 dBm

Weight and Dimensions

weight	238 g
dimensions	45 x 118 x 164 mm
