TRENDnet User’s Guide
TEW-750DAP
32
Wireless Range Extender (AP Repeater)
Wireless range extender or repeater mode allows the device to extend the range of an existing wireless network. The existing wireless signal can be broadcasted from your wireless
router or other access point. In addition, other network enabled devices can connect to your network using the Ethernet LAN ports. The functionality of this mode is similar to WDS with
Access Point however, wireless range extender mode does not require the other wireless device to support repeater or WDS and can only function using one band at a time, 2.4GHz or
5GHz and other modes cannot be used simultaneously. The diagram illustrates an example of the device repeating the signal of an existing access point. Wireless client devices can
connect to which ever signal is stronger.

TRENDnet TEW-750DAP Specifications

Operating Environment

operating temperature	0 - 40 °C
operating humidity	Max. 95% non-condensing

Power

input voltage	100 - 240 V AC
output voltage	12 V DC
power consumption	10.1 Watts

Antenna and Wireless

antenna gain 2.4 GHz	2 x 1.5 dBi
antenna gain 5 GHz	2 x 4 dBi
wireless output power 802.11a	15 dBm

Weight and Dimensions

weight	238 g
dimensions	45 x 118 x 164 mm
