Technical Specifications
Hardware
Standards
Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX),
Wireless: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b, IEEE 802.11a
Internet Protocol IPv4 and IPv6
Ports 4 x 10/100 Mbps Ethernet (Auto-MDIX)
WPS Button
Wi-Fi Protected Setup (WPS) connects with other WPS compliant
devices
Reset Button Reset unit back to factory default (press and hold for 10 seconds)
Network
Protocols /
Features
Static IP, DHCP Server/Client, NTP, IPv6
Management
/ Monitoring
Local / remote configuration, upgrade firmware, backup / restore
configuration via web browser, internal system log (Categories:
System, Access Point Status: Critical, Warning, Information), syslog,
email log, wireless client list
Supported
Web Browser
Internet Explorer 8.0 or above, Firefox, Chrome, Opera, Safari
LED Indicator Power, Ethernet 1-4, Wireless (2.4GHz/5GHz), WPS
Power Adapter
Input: 100 ~ 240 V, 50~60 Hz, 0.4 A
Output: 12 V DC, 1 A external power adapter
Power
Consumption
10.1 watts (max.)
Dimension (L x W
x H)
45 x 118 x 164 mm (1.8 x 4.6 x 6.5 in.)
Weight 238 g (8.4 oz)
Temperature
Operation: 0° ~ 40°C (32°F ~ 104°F)
Storage: -20° ~ 65°C (-4°F ~ 149°F)
Humidity Max. 95% (non-condensing)
Certifications CE, FCC
Wireless
Frequency
2.4 GHz: 2.412~2.462 (FCC) and 2.412~2.483 (ETSI)
5 GHz: 5.15 ~ 5.35 / 5.725~5.825 GHz (FCC) and 5.15 ~ 5.35 / 5.47 ~
5.725 (ETSI)
Modes Access Point (AP), AP+WDS, WDS only, Repeater, Client Bridge
Antenna
2.4 GHz: 2 x 1.5 dBi PIFA internal
5 GHz: 2 x 4 dBi PIFA internal
Modulation CCK, DQPSK, DBPSK, OFDM, BPSK, QPSK, 16/64-QAM
Data Rate
802.11a: up to 54 Mbps
802.11b: up to 11 Mbps
802.11g: up to 54 Mbps
802.11n: up to 300 Mbps (for both 2.4 & 5 GHz)
Security 64/128-bit WEP, WPA/WPA2-PSK, WPA/WPA2-RADIUS
SSIDs 4 SSIDs per band
WDS Up to 4 WDS bridge connections per band
Output Power
802.11a: 18 dBm (typical)
802.11b: 18 dBm (typical)
802.11g: 18 dBm (typical)
802.11n: 15 dBm (typical) (for 2.4 & 5GHz)
Receiving
Sensitivity
802.11a: -65 dBm (typical) @ 54 Mbps
802.11b: -76 dBm (typical) @ 11 Mpbs
802.11g: -65 dBm (typical) @ 54 Mbps
802.11n: -61 dBm (typical) @ 300 Mbps (for 2.4 & 5 GHz)
Channels
2.4 GHz: 1~11 (FCC), 1~13 (ETSI)
5 GHz: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC) 36, 40, 44, 48 (ETSI)
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual
data throughput and coverage will vary depending on interference, network traffic, building
materials and other conditions.

TRENDnet TEW-750DAP Specifications

Operating Environment

operating temperature	0 - 40 °C
operating humidity	Max. 95% non-condensing

Power

input voltage	100 - 240 V AC
output voltage	12 V DC
power consumption	10.1 Watts

Antenna and Wireless

antenna gain 2.4 GHz	2 x 1.5 dBi
antenna gain 5 GHz	2 x 4 dBi
wireless output power 802.11a	15 dBm

Weight and Dimensions

weight	238 g
dimensions	45 x 118 x 164 mm
