16 Juno Series Handhelds User Guide
Figure 1.2 Juno series handheld – bottom view
Figure 1.3 Juno series handheld - back view
Powering the handheld
The Juno series handheld contains a rechargeable Lithium-ion battery.
Note – C
harge the battery completely before using the handheld for the first time. If the
battery has been stored for longer than six months, charge it before use. Trimble
recommends charging the battery for four hours to recharge it fully.
Note – Cold
temperatures, or using Bluetooth wireless technology or Wi-Fi connectivity, or
using the cellular modem consumes additional battery power and so shortens battery life
between charges.
Mini USB socket
Stylus and wrist
Stylus
Power connector
lanyard tether
Camera lens
Camera flash
(Juno 3D only)
Back cover lock
Speaker
