Trimble R7/R8 GPS Receiver User Guide 23
Setting up the Receiver 3
Trimble R7 Operation
Figure 2.7 shows the Trimble R7 receiver pole-mounted setup.
Figure 3.7 RPA and bracket
4. Mount the Zephyr antenna on the range pole.
5. Connect the GPS antenna cable. Make sure that the GPS cable
is not hanging over the top of the RPA.
6. Connect the blue TNC-to-TNC radio cable to the RPA.
RPA
GPS antenna
cable
Pole
RPA
bracket
TNC port
(aligned over
antenna cable)
