Trimble R7 User Manual

3 Setting up the Receiver
34 Trimble R7/R8 GPS Receiver User Guide
Trimble R7 Operation
information, refer to the document Using Cellular and CDPD
Modems for RTK, which is available from your local Trimble
Distributor.
Figure 3.13 shows the components required to connect a cellphone to
a Trimble R7 receiver.
Figure 3.13 Connecting a cellphone
For more information on using a cellular modem as a data link, refer to
the Trimble Survey Controller User Guide.
Serial cable
DB9 to Lemo cable
