3 Working with the unit and battery
1. Close open applications and save data, in case the battery exchange takes too long.
2. Remove the hand strap from the unit.
3. Enter the Replace Battery mode (so alarms will not wake up the unit while changing the
battery). Hold down the Power key for about 3 seconds then release to display the power
menu. Tap Replace Battery/SIM. See page 33.
4. Turn the latch located above the battery counterclockwise.
5. Remove the battery from the unit.
6. Quickly insert the replacement battery onto the unit.
7. Turn the latch located above the battery clockwise.
8. Replace the hand strap.
9. Turn on the unit to resume operation.
Battery power: Tap / Settings / Power to see how much battery power is remaining. Tap
Advanced to turn the display off when not in use to conserve battery power.
Notification LEDs
At the top of the unit are three LEDs that provide status information:
Left LED Center LED Right LED
Colors: amber, green,
red
Colors: amber, green, red Colors: amber, blue, green
Battery Status
Green: fully
charged
Amber: charging
Red: battery error
OS Status
(application dependent)
Red: battery error
WWAN Status:
Amber-blinking: 2G connection
Green-blinking: 3G connection
(if OS status alarm and WWAN is on,
the red will blink faster)
Bluetooth on
Blue-blinking
Wi-Fi on
Amber-blinking
GPS on
Green-blinking
(LED will flash in a sequence if
multiple features are on)
Battery power: Tap / Settings / Power to see how much battery power is remaining. Tap
Advanced to turn the display off when not in use to conserve battery power.
Ranger Series Handheld Computer 32
