Triumph Sprint ST Handbook

24
General Information
Fuel Gauge
1. Fuel gauge
The fuel gauge indicates the amount of fuel
in the tank.
With the ignition switched on, the number of
bars shown in the display indicates the level
of fuel in the tank.
When the fuel tank is full, all 10 bars are
displayed and when empty, no bars are
displayed. Other gauge markings indicate
intermediate fuel levels between full and
empty.
When 2 bars are displayed, the low fuel
warning light will illuminate. This indicates
there are approximately 4.0 litres of fuel
remaining in the tank and you should refuel
at the earliest opportunity.
After refuelling, the fuel gauge and range to
empty information will be updated only while
riding the motorcycle.
Depending on the riding style, this could take
approximately 5 minutes.
Caution
Do not continue to run the engine if either
of the high temperature warnings are
displayed as severe engine damage may
result.
ccni
1

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
