Triumph Sprint ST Handbook

49
How to Ride the Motorcycle
Braking
1. Front brake lever
1. Rear brake pedal
Warning
WHEN BRAKING, OBSERVE THE
FOLLOWING:
Close the throttle completely, leaving the
clutch engaged to allow the engine to help
slow down the motorcycle.
Change down one gear at a time such that
the transmission is in first gear when the
motorcycle comes to a complete stop.
When stopping, always apply both brakes
at the same time. Normally the front brake
should be applied a little more than the
rear.
Change down or fully disengage the clutch
as necessary to keep the engine from
stalling.
Never lock the brakes, as this may cause
loss of control of the motorcycle and an
accident.
2
1
3
4
1
jaim
Warning
For emergency braking, disregard down
changing, and concentrate on applying the
front and rear brakes as hard as possible
without skidding. Riders should practice
emergency braking in a traffic-free area.
(See ABS warnings below/over.)
Triumph strongly recommends that all
riders take a course of instruction, which
includes advice on safe brake operation.
Incorrect brake technique could result in
loss of control and an accident.
1
ceyr

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
