Page #25 background image
25
General Information
Warning Lights
Direction Indicators
When the indicator is pushed to
the left or right, the
corresponding turn indicator
light will flash on and off at the
same speed as the turn indicators.
High Beam
When the ignition is switched
on and the headlight dip switch
is set to 'high beam', the high
beam warning light will illuminate.
Low Fuel
The low fuel indicator will
illuminate when there are
approximately 4.0 litres of fuel
remaining in the tank.
Neutral
The neutral warning light
indicates when the transmission
is in neutral (no gear selected).
The warning light will illuminate when the
transmission is in neutral with the ignition
switch in the ON position.
Low Oil Pressure Warning Light
With the engine running, if the
engine oil pressure becomes
dangerously low, the low oil
pressure warning light in the tachometer will
illuminate.
The low oil pressure warning light in the
tachometer will illuminate if the ignition is
switched on without running the engine.
High Coolant Temperature Warning
Light
With the engine running, if the
engine coolant temperature
becomes dangerously high, the
high coolant temperature
warning light in the tachometer will
illuminate.
The high coolant temperature warning light
in the tachometer will illuminate if the ignition
is switched on without running the engine.
Caution
Stop the engine immediately if the low oil
pressure warning light illuminates. Do not
restart the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the low oil
pressure warning light is illuminated.
Caution
Stop the engine immediately if the high
coolant temperature warning light
illuminates. Do not restart the engine until
the fault has been rectified.
Severe engine damage will result from
running the engine when the high coolant
temperature warning light is illuminated.

Table of Contents

Other manuals for Triumph Sprint ST

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Triumph Sprint ST and is the answer not in the manual?

Triumph Sprint ST Specifications

General IconGeneral
Engine TypeLiquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement1050cc
Bore x Stroke79 x 71.4 mm
Compression Ratio12.0:1
Fuel SystemMultipoint sequential electronic fuel injection
Final DriveX ring chain
ClutchWet, multi-plate
Gearbox6-speed
Rear SuspensionMonoshock with adjustable preload and rebound damping
Rear BrakesSingle 255mm disc, 2-piston caliper
Front Wheel17 x 3.5 in
Rear Wheel17 x 5.5 in
Front Tyre120/70 ZR 17
Rear Tyre180/55 ZR 17
Max Power125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque104 Nm / 77 ft-lb @ 5, 000 rpm
FrameAluminum beam perimeter
Front Suspension43 mm
Front BrakesTwin 320 mm floating discs, 4 piston calipers
Seat Height805 mm
Dry Weight210 kg
Fuel Tank Capacity20 liters
