Triumph Sprint ST Handbook

37
General Information
Seat Care
To prevent damage to the seat or seat cover,
care must be taken not to drop or lean the
seat against any surface which may damage
the seat or seat cover.
To refit the seat, engage the seat's tongue
under the fuel tank and press down at the
rear to engage. Tighten the seat fasteners to
3 Nm.
Pannier System
To install each pannier:
Note:
• The pannier is marked in three
positions around the lock barrel.
To lock, release or open the
panniers, the key slot must align
with the corresponding markings
around the barrel as shown.
1. Key slot (shown in the LOCK
position)
Caution
To prevent damage to the seat or seat
cover, care must be taken not to drop the
seat. Do not lean the seat against the
motorcycle or any surface which may
damage the seat or seat cover. Instead,
place the seat, with the seat cover facing
upwards, on a clean, flat surface which is
covered with a soft cloth.
Do not place any item on the seat which
may cause damage or staining to the seat
cover.
R
E
L
E
A
S
E
•
•
L
O
C
K
•
O
P
E
N
R
E
L
E
A
S
E
•
•
L
O
C
K
•
O
P
E
N
1

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
