Triumph Sprint ST Handbook

35
General Information
Whenever the side stand is used before
riding, always ensure that the stand is fully up
after first sitting on the motorcycle.
For instructions on safe parking, refer to the
'How to Ride the Motorcycle' section.
Centre Stand
1. C e n t r e s t a n d
2. Lifting handle
To set the motorcycle up on the centre stand,
step down firmly on the foot-finder part of
the stand, then lift the motorcycle up and to
the rear using the lifting handle as a
handhold.
For instructions on safe parking, refer to the
'How to Ride the Motorcycle' section.
Lifting Handle
The lifting handle is located on the left hand
side of the motorcycle, and is the upper edge
of the pillion footrest hanger.
Always use the lifting handle to park the
motorcycle on the centre stand.
1
2
ccpo
Warning
Do not use the side panel or seat as a
hand-hold when placing the motorcycle on
the centre stand as this will cause damage.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
