Triumph Sprint ST Handbook

29
General Information
Brake and Clutch Lever
Adjusters
1. Adjuster wheel
2. Triangular mark
An adjuster is fitted to both the front brake
and clutch levers. The adjusters allow the
distance from the handlebar to the levers to
be changed to one of four positions, to suit
the span of the operator's hands.
To adjust the levers, push each lever forward
and turn the adjuster wheel to align one of
the numbered positions with the triangular
mark on the lever holder.
The distance from the handlebar grip to the
released lever is shortest when set to number
four and longest when set to number one.
Warning
Do not attempt to adjust the levers with the
motorcycle in motion as this may lead to
loss of motorcycle control and an accident.
After adjusting the levers, operate the
motorcycle in an area free from traffic to
gain familiarity with the new lever setting.
Do not loan your motorcycle to anyone as
they may change the lever setting from the
one you are familiar with causing loss of
control or an accident.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
