Triumph Sprint ST Handbook

33
General Information
Fuel Tank Cap
1. Ignition switch key
2. Fuel tank cap
To open the fuel tank cap, lift up the flap
covering the lock itself. Insert the key into the
lock and turn the key clockwise.
To close and lock the cap, push the cap down
into place with the key inserted, until the lock
'clicks' into place. Withdraw the key and close
the key cover.
Filling the Fuel Tank
Avoid filling the tank in rainy or dusty
conditions where airborne material can
contaminate the fuel.
Fill the fuel tank slowly to help prevent
spillage. Do not fill the tank to a level above
the bottom of the filler neck. This will ensure
there is enough air space to allow for fuel
expansion if the fuel inside the tank expands
through absorption of heat from the engine
or from direct sunlight.
1. Maximum fuel level
2. Fuel filler neck
3. Air space
After refuelling always check that the fuel
filler cap is correctly closed and locked.
Caution
Closing the cap without the key inserted
will damage the cap, tank and lock
mechanism.
1
2
cbmm
Caution
Contaminated fuel may cause damage to
fuel system components.
1 2 3
cbdf

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
