Triumph Sprint ST Handbook

31
General Information
Left Handlebar Switches
1. Headlight dip switch
2. Direction indicator switch
3. Horn button
4. Pass button
Headlight Dip Switch
High or low beam can be selected with the
headlight dip switch. To select high beam,
push the switch forward. To select low beam,
push the switch rearwards. When the high
beam is turned on, the high beam indicator
light will illuminate.
Note:
• A lighting on/off switch is not
fitted to this model. The headlight,
rear light and licence plate light all
function automatically when the
ignition is turned to the ON
position.
Direction Indicator Switch
When the indicator switch is pushed to the
left or right and released, the corresponding
direction indicators will flash on and off. To
turn off the indicators, push and release the
switch.
Horn Button
When the horn button is pushed, with the
ignition switch turned to the ON position, the
horn will sound.
Pass Button
When the pass button is pressed, the
headlight main beam will be switched on. It
will remain on as long as the button is held in
and will turn off as soon as the button is
released.
ccml
4
3
2
1

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
