Triumph Sprint ST Handbook

30
General Information
Right Handlebar Switches
1. Engine stop switch
2. Starter button
Engine Stop Switch
In addition to the ignition switch being turned
to the ON position, the engine stop switch
must be in the RUN position for the
motorcycle to operate.
The engine stop switch is for emergency use.
If an emergency arises which requires the
engine to be stopped, move the engine stop
switch to the STOP position.
Note:
• Although the engine stop switch
stops the engine, it does not turn
off all the electrical circuits and
may cause difficulty in restarting
the engine due to a discharged
battery. Ordinarily, only the
ignition switch should be used to
stop the engine.
Starter Button
The starter button operates the electric
starter. For the starter to operate, the clutch
lever must be pulled to the handlebar.
Note:
• Even if the clutch lever is pulled to
the handlebar, the starter will not
operate if the side stand is down
and a gear is engaged.
ccmm
2
1
Caution
Do not leave the ignition switch in the ON
position unless the engine is running as
this may cause damage to electrical
components and will discharge the battery.

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
