Triumph Sprint ST Handbook

77
Maintenance and Adjustment
Chain Lubrication
Lubrication is necessary every 200 miles and
also after riding in wet weather, on wet roads,
or any time that the chain appears dry.
Use the special chain lubricant as
recommended in the Specification section.
Apply lubricant to the sides of the rollers then
allow the motorcycle to stand unused for at
least 8 hours (overnight is ideal). This will
allow the oil to penetrate to the chain O-rings
etc.
Before riding, wipe off any excess oil.
If the chain is especially dirty, clean first and
then apply oil as mentioned above.
Chain Free-Movement Inspection
1. Maximum movement position
Park the motorcycle on the side stand.
Rotate the rear wheel to find the position
where the chain is tightest, and measure the
vertical movement of the chain midway
between the sprockets.
The vertical movement of the drive chain
must be in the range 35 - 40 mm.
Caution
Do not use a pressure wash to clean the
chain as this may cause damage to the
chain components.
Warning
Before starting work, ensure the
motorcycle is stabilised and adequately
supported. This will help prevent injury to
the operator or damage to the motorcycle.
1
ccmv

Triumph Sprint ST Specifications

General

Engine Type	Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Displacement	1050cc
Bore x Stroke	79 x 71.4 mm
Compression Ratio	12.0:1
Fuel System	Multipoint sequential electronic fuel injection
Final Drive	X ring chain
Clutch	Wet, multi-plate
Gearbox	6-speed
Rear Suspension	Monoshock with adjustable preload and rebound damping
Rear Brakes	Single 255mm disc, 2-piston caliper
Front Wheel	17 x 3.5 in
Rear Wheel	17 x 5.5 in
Front Tyre	120/70 ZR 17
Rear Tyre	180/55 ZR 17
Max Power	125 PS / 123 bhp / 92 kW @ 9, 250 rpm
Max Torque	104 Nm / 77 ft-lb @ 5, 000 rpm
Frame	Aluminum beam perimeter
Front Suspension	43 mm
Front Brakes	Twin 320 mm floating discs, 4 piston calipers
Seat Height	805 mm
Dry Weight	210 kg
Fuel Tank Capacity	20 liters
