AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
32
Table1-6-9 V/W Limit Signal Input
PIN
Name
Instruction
10.V/W Limit
1
DC24V
Output DC voltage (24V).
2
ELW+
The hard limit of W axis. The input signal of hard
limit sensor, when W axis moves to the
maximum coordinate position.
3
ELV+
The hard limit of V axis. The input signal of hard
limit sensor, when V axis moves to the
maximum coordinate position.
4
ELW-
The origin limit of the W axis. The input signal
of origin limit sensor, when the W axis moves to
the minimum coordinate position (zero
position).
5
ELV-
The origin limit of the V axis. The input signal of
origin limit sensor, when the V axis moves to the
minimum coordinate position (zero position).
6
GND
Power ground.
