AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
31
2
ELU+
The hard limit of U axis. The input signal of hard
limit sensor, when U axis moves to the
maximum coordinate position.
3
ELZ+
The hard limit of Z axis. The input signal of hard
limit sensor, when Z axis moves to the
maximum coordinate position.
4
ELU-
The origin limit of the U axis. The input signal of
origin limit sensor, when the U axis moves to the
minimum coordinate position (zero position).
5
ELZ-
The origin limit of the Z axis. The input signal of
origin limit sensor, when the Z axis moves to the
minimum coordinate position (zero position).
6
GND
Power ground.
