AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
30
Table1-6-7 X/Y Limit Signal Input
PIN
Name
Instruction
8.X/Y Limit
1
DC24V
Output DC voltage (24V).
2
ELY+
The hard limit of Y axis. The input signal of hard
limit sensor, when Y axis moves to the
maximum coordinate position.
3
ELX+
The hard limit of X axis. The input signal of hard
limit sensor, when X axis moves to the
maximum coordinate position.
4
ELY-
The origin limit of the Y axis. The input signal of
origin limit sensor, when the Y axis moves to the
minimum coordinate position (zero position).
5
ELX-
The origin limit of the X axis. The input signal of
origin limit sensor, when the X axis moves to the
minimum coordinate position (zero position).
6
GND
Power ground.
Table1-6-8 Z/U Limit Signal Input
PIN
Name
Instruction
9.Z/U Limit
1
DC24V
Output DC voltage (24V).
