AWC708C PLUS Motion Control User Manual
WWW.SZTROCEN.COM
65
(mm/s2)
this value increases or decreases in unit of 50 or
100 each time.
Engrave Acc
(mm/s2)
The variation of engraving speed and it is only
effective to engrave.
Start Speed
(mm/s)
The initial speed of laser head from rest to motion.
Speed Factor
Parameter changes throughout the system. We
suggest that lower speed is going to be filled in
with 0.5 or 1, while regular speed with 2 and high
speed with 3 or 4. This option should be filled in
with 0.05 when cutting acrylic or wood. It also has
an impact on smoothness when turning.
During cutting process, if the actual cutting speed is far less than the
working speed users have set, it indicates that the【Cut Jerk】is set too
small, so that the laser head cannot reach the set working speed quickly.
If the actual cutting speed is relatively fast, the cutting line will jitter, this
case indicates that the【Cut Jerk】is set too high and the parameter value
should be reduced. In the same way, if the【Space Jerk】is set too small,
the speed of laser head will not reach the set speed when there is no laser
output. If the parameter is set too large, the initial position of cutting
(after the laser head moving without laser) will jitter.
