AWC708C PLUS supports MultiHead function, when single laser head
works, fill “1” into【Head Count】, when two or more laser heads work,
fill “2” / “3” / “4” into the【Head Count】.
Users can set single belt or double belt according to the need. Under
double belts condition, if one of the belts becomes loose, the cutting
effect of the laser head becomes worse, while the cutting effect of the
other laser head is not affected.
When the Laser head1 and Laser head2 cutting together, if enable the
【Nearer Laser for LeftOver】function, cutting to the edge of the graphics
where the main laser head can’t cut, the Laser head2 will continue cutting
automatically. If disable the function, when cutting to the position where
the Laser head1 can’t cut, then the part of the file can’t be cut. The
common cutting of laser heads 1 and 2 is shown in Figure 7-6-2, while the
mutual movable double laser head cutting is shown in Figure 7-6-3.
