Chapter 3: Locations Center Console Models • Owner’s Manual Supplement
Holding Tank or Portable Toilet Pump-out
Deck Fitting (If Equipped) - 2503: Located on
the starboard side deck.
Hydraulic Steering Fluid Reservoir (If Equipped):
Located on the steering column.
Macerator Switch (If Equipped) - 2503: Access
through the aft wall hatch in the head compartment.
Macerator Underwater Discharge Seacock (If
Equipped) - 2503: Access through the aft wall
hatch in the head compartment.
Marine Head Seawater Intake Seacock (If
Equipped) - 2503: Access through the aft wall
hatch in the head compartment.
HOLDING TANK
PUMP-OUT
DECK FITTING
HYDRAULIC FLUID
RESERVOIR CAP
UNDERWATER
DISCHARGE
SEACOCK
SEAWATER
INTAKE
SEACOCK
MACERATOR
SWITCHES
MACERATOR
