33
Center Console Models • Owner’s Manual
Supplement
Chapter 3: Locations
Navigation Lights - 1703:
• Red and green running light is
located on the bow.
• White all-round light is located on
the starboard side of the stern.
Navigation Lights - 1903:
• Red and green running light is
located on the bow.
• White all-round light is located on
the starboard side of the stern or on
top of the t-top (if equipped).
Navigation Lights - 2103 & 2503:
• Red and green running lights are
located on the bow.
• White all-round light is mounted on
the windshield or on top of the t-top
(if equipped).
STERN ALL-ROUND
LIGHT BASE
BOW
T-TOP
A
F
T
WHITE ALL-ROUND
LIGHT
LIGHT
2503
2103
BOW LIGHTS
WHITE ALL-ROUND
LIGHT
T-TOP
A
F
T
F
O
R
W
A
R
D
F
OR
W
A
R
D
