Chapter 3: Locations Center Console Models • Owner’s Manual
Supplement
Portable Toilet Pump-out Deck Fitting (If
Equipped) - 2103: Located on the port side
deck.
Oil Fill Deck Fitting - 2103: Located on the port
aft deck, next to the oil storage container.
Oil Fill Deck Fitting - 2503: Located under the
starboard aft deck access hatch lid.
PORTABLE TOILET PUMP-
OUT DECK FITTING
OIL FILL
DECK FITTING
OIL STORAGE
CONTAINER
OIL FILL
DECK FITTINGS
ACCESS HATCH LID
